A working DIY method with real dimensions, margins and print settings, plus the point where buying beats printing.
You can make usable name badges in Word or Google Docs in about fifteen minutes using a table sized to the badge dimensions, a 0.125 inch safe margin inside each cell, and a printer set to actual size rather than fit to page. The result is right for a one-day event. It is not right for staff who wear a badge every shift, because paper and inkjet ink do not survive a work week.
Set the page up correctly first
- Page size US Letter, margins 0.5 inch on all four sides.
- Insert a table: 2 columns and 5 rows gives you ten 3 inch wide badges per sheet.
- Set the column width to exactly 3 inches and the row height to exactly 1 inch, or 1.5 inches for the larger size. Set row height to Exactly, not At least, or the text will push the cell taller.
- Cell margins 0.125 inch all round. That is your safe area. Nothing important goes outside it.
- Center text vertically and horizontally in each cell.
Type sizes that actually read
| Line | Point size | Reads from |
|---|---|---|
| First name | 26 to 28 pt semibold | About 5 feet |
| Full name | 20 to 22 pt semibold | About 4 feet |
| Title or department | 12 to 14 pt regular | About 3 feet |
| Company line | 10 to 11 pt regular | Close up only |
Measured on a 1 x 3 inch layout with a 0.125 inch margin.
Printing without the drift
In the print dialog, choose Actual size or set scaling to 100 percent. Fit to page is the single most common reason a sheet of DIY badges comes out 3 or 4 percent small and stops lining up with a holder. Print one test sheet on plain paper, measure a badge with a ruler, and only then load the card stock. Use 65 lb cover or heavier if the insert goes in a holder, since 20 lb copy paper curls inside a plastic window within a day.
Google Docs differences
- Table properties lets you set column width and minimum row height, but there is no exact row height. Keep the font size at or under the values above so rows do not grow.
- Cell padding replaces cell margins. Set it to 0.125.
- Download as PDF before printing. Printing straight from the browser reintroduces scaling.
Where DIY stops making sense
Paper inserts are fine for a conference, a school open house or a one-off training day. Once the same person wears the same badge daily, the maths changes: a printed plastic badge starts at $8.99 each and drops to $7.49 at 101 pieces, and it lasts years rather than a week. Between the card stock, the holders, the ink and the hour someone spends laying it out, a DIY program for a permanent team usually costs more, not less.
Print your own for a day. Buy them for a job.
Our free templates page has the same layouts already set to true dimensions with safe margins marked, so you can skip the table setup entirely.
